EPC Automatic Crude Palm Centrifugal Oil Purifier Lube Oil Purifier

EPC Processing of stainless steel and Automatic Crude Palm Oil Purifier

1. Application

This Palm Oil Purifier is  is used to purify the palm oil that overflows from the top of the mill's main settling tank. It removes impurities and insoluble water from the crude palm oil. It's operation is fully automated.

2. Operating principle

This palm oil purifier is a solids ejecting disc stack centrifuge. It's rotating bowl is driven by an electric drive motor via a flat belt and friction clutch. The suspension to be separated is fed into the separator bowl from the top through a feeding pipe and enters the disc stack (3). The heavy phase and heavy sludge are forced towards the periphery of the bowl, while the light phase

flows towards the centre of the bowl, from where it is pumped out for further processing. The heavy phase is led over a top disc into a chamber where a paring device pumps it out of the separator. Sludge collects in the sludge space and is discharged intermittently and automatically. The discharge is achieved by a hydraulic system, which at preset suitable intervals forces

the sliding bowl bottom to drop down, thus opening the sludge ports at the bowl periphery. The sludge is collected in the frame, and leaves the centrifuge via a cyclone.

3. Features

• All parts of the product are made of stainless steel
• Self-cleaning bowl
• Total ejections and partical ejections
• Flat-belt drive design
• Higher G-force

4. Your benefits

• Better separation efficiency
• Automated operation
• Continuous processing mode
• Simple maintenance
• Closed discharge of theliquid phase
• Low-noise design
