Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology

China Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology supplier
Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology supplier Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology supplier Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology supplier Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology supplier Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology supplier

Large Image :  Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology

Product Details:

Place of Origin: KANGWEI
Brand Name: KANGWEI POWER
Certification: BV/IEC
Model Number: KWEE200

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Packaging Details: container
Delivery Time: Negotiated
Supply Ability: Negotiated Period
Contact Now
Detailed Product Description
Fuel: Wooden Straw Palm Power: 200/350/400/450/500/800/1000/1200kw
Voltage: 380/415/440/660V

Biomass Gasification power plant 200 - 1000kw Combined Heat and Power technology

         The objective of the biomass gasification process is the best possible conversion of solid biomass fuels into a high calorific product gas. Thereby, biomass reacts with a fumigator (air, oxygen, steam or CO2), which provide oxygen for the process. Due to the thermal cracking and the partial oxidation a product gas is formed. The composition of the product gas depends on the biomass fuel, the reaction conditions and the fumigator and consists of different concentrations of hydrogen (H2), carbon monoxide (CO), steam (H2O) and methane (CH4). In case of air as fumigator the product gas includes nitrogen (N2) as well. Char coal, ash with varying carbon contents and condensable low molecular hydrocarbons are produced besides the product gas. The char coal and the hydrocarbons (summarised as tar) are the products of an incomplete gasification.



      The gasification process include four stages:

  • Drying
  • Pyrolysis
  • Oxidation
  • Reduction

Typical product gas composition

Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology
            Our biomass gasification process includes three steps. The First step is biomass gasification, which convert
biomass into syngas. The Second step is syngas purification. The producer gas coming from gasifier usually
contains contaminants including dust, coke, tar and etc. The contaminants will be removed by the purification
system to ensure normal operation of gas engine. The Third step is power generating in gas engine. The high
temperature exhaust gas may be reused by waste heat boiler to generate steam or hot water for civil or industrial
use). Steam turbine may also be considered to make a gas-steam combined cycle power plant, which will
increase the total efficiency.
         Biomass Material:
One 2MW biomass gasification power plant will need dry biomass about 2200-3600kg/hour,according to 8000 running hours per year, then annual maximum consumption of biomass will be 28800 MT/year.

Biomass Gasification Power Plant technologies Flow Chart



Biomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power TechnologyBiomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power TechnologyBiomass Gasification Fired Power Plant 200 - 1000kw Combined Heat Power Technology
