ZRG-0.5 50Hz 60Hz Steam Heating Marine Hot Water Tanks with 500L
Descrition:
This series electrical or steam hot water tank is suitable for all kinds of ship.it has compact structure and easy to maintain, it is an ideal water supply unit.
The combined pressure water tank provided with vertical or horizontal water tank, the consumer can select according to the fact
Applications:
Ship , vessel, industrial
ZRG steam heating hot-water tank
Main technical data
| Model | Capacity | Design pre. | Working pre. | Water inlet temp. | Water outlet temp. | Steam pre. | Hot-water capacity | Steam consume | Source | Weight |
| m3 | Mpa | Mpa | ℃ | ℃ | Mpa | kg/h | kW | kg | ||
| ZRG-0.12 | 0.12 | 0.45 | 0.4 | 15 | 65 | 0.3 | 275 | 27.5 | 380V 50Hz | 170 |
| ZRG-0.2 | 0.2 | 450 | 45 | or | 200 | |||||
| ZRG-0.3 | 0.3 | 750 | 75 | 440V 60Hz | 260 | |||||
| ZRG-0.5 | 0.5 | 1200 | 120 | 390 |
